Beer Glass Bottle Filling Machine

HG-CGF type beer bottle washing filling capping monoblock is designed combined with the actual situation in our country after the introduction and absorption that comes from Germany technologies. It adopts isobaric filling principle and filling valve adopts high precision mechanical valve. It...

Send Inquiry

Product Details

blob.png blob.png

HG-CGF661 type beer bottle washing filling capping monoblock is designed combined with the actual situation in our country after the introduction and absorption that comes from Germany technologies.

It adopts isobaric filling principle and filling valve adopts high precision mechanical valve. It has advantages of fast filling speed, high precision in liquid level. Adopt MITSUBISHI automatic controlling system, realizing trinity of the machines, and control the washing, filling and capping process.

(1) Adopts high precision mechanical valve, has advantages of fast filling speed, high precision in liquid level.

(2) Sealed filling cylinder made of 304 stainless steel and automatic adjustment of the liquid level to realize isobaric filling.

(3) Has CIP cleaning function, touching screen control, the whole machine is protected by stainless door.

(4) Adopt vacuumization and CO 2 preparing pressure principal, and then prepare pressure for a second time to make sure the filling quality.

Working principle:

Bottle rinsing part: 6 nozzles

This part is made up of lifting device, the main transmission device, the fixed frame, clamp device,

distributor, and open clamp cams and over turn cams etc.

beer bottling linebeer bottling equipment

Filling part: 6 nozzles

The filling part is made up of main liquid pipe, rotating cylinder bearing base, filling cylinder fulcrum loop,carbonated beverage and beer tank, filling valve, filling cylinder pipe, control loop device, ascending device,the distributor, height adjusting control, stimulating bubble arm, vacuum system, etc.

labeling machinemanual beer filler

beer bottling plant equipment

Capping part: 1 head

The capping machine is made up of cap holder, capping slideway, capping upper part, capping lower part,elevating part and anti-circling column.


Technology data:


ItemParameters
Washing heads6
Filling heads6
Capping heads1
Capacity 300-600BPH
Bottle type  height:150~ 300mm

bottle neck:①50~①85mm

bottle diameter: 50-75mm

Air consumption  0. 2m 3 /min (0. 4~0.6Mpa)
CO 2 consumption  1.6kg/l000L
Water consumption0. 8m3/h
Vacuum pump  0. 20m 3 /h
Power

main motor: 1.5KW

hopper motor: 0 .18KW

vacuum pump motor: 1.1 KW

washing pump motor: 0.37KW chain

motor: 0.37KW

Dimensions  1650×1180×2400(L*W*H)
N.W.  1500Kg
Frequency converter  SIEMEMS
PLC  SIEMEMS
Touch screen  SIEMEMS
Pneumatic element  SMC


Beer Bottling Machinesbeer bottle filling machine



Accessory:

Filter:

The filtering capacity of this filter is made of excellent SS304, and has a good filtering precision, small material loss, strong corrosion resistance. Disassembling is unnecessary when cleaned, and its anywhere can be well cleaned. It mainly used in Beer, Fruit wine, Beverage, Sugar, Seasoning, Medicine, Chemical industry.

beer bottling machine cost

Rotary Worktable:

It is for sorting the bottles before filling.

Dimension: φ900*1300mm

Material: Stainless steel 304



6/6/1 beer washing filling capping monoblock:

HG-CGF6/6/1 type bottle washing filling capping monoblock is designed combined with the actual situation

in our country after the introduction and absorption that comes from Germany technologies.

Beer Bottling Plant

Tunnel pasteurizer:

This spray warm and cooling machine also named tunnel pasteurizer, which is different from the direct heat method (instantaneous sterilization), tunnel pasteurizer sterilize products and containers together, so that you can eliminate various possible causes of the growth of harmful bacteria within the allowed time.

Bottle dryer:

1. This machine is applicable for drying the bottles before labelling.

2. The wind direction is adjustable. The wind mouth can also be adjusted according to actual situation.

3. Almost every kind and size of bottles can be dried by this machine.

4. Low energy cost.

5. No easy-wear accessories or parts.

Beer filler
Beer filling equipment

Labeling machine:

Self adhesive labeling maachine, used for round and square bottle.

It can label one, two or three labels.

Printer

1. Easy to operate.

2. This machine would print in many different languages.

3. Display the product code, batch, etc.

4. It can print 3 lines, numbers and other characters in English version.

beer filling line
beer filling system

Packing machine:

It is used to pack plastic film package.

Details:

beer filling plant

Our clients:

Beer filling machine

Package:

filling line
